Wimberley AP-603 Replacement Foot - Canon 200-400 IS, 300 2.8 IS II, 500 4.0 IS II and 400 4.0 DO IS II

Article number:

12305487

Wimberley AP-603 Replacement Foot - Canon 200-400 IS, 300 2.8 IS II, 500 4.0 IS II and 400 4.0 DO IS II
Wimberley AP-603 Replacement Foot - Canon 200-400 IS, 300 2.8 IS II, 500 4.0 IS II and 400 4.0 DO IS II
  • Wimberley AP-603 Replacement Foot - Canon 200-400 IS, 300 2.8 IS II, 500 4.0 IS II and 400 4.0 DO IS II
List price £129,-
£110,-
On order
Wimberley AP-603 Replacement Foot - Canon 200-400 IS, 300 2.8 IS II, 500 4.0 IS II and 400 4.0 DO IS II
Wimberley AP-603 Replacement Foot - Canon 200-400 IS, 300 2.8 IS II, 500 4.0 IS II and 400 4.0 DO IS II
£110,-

Get notified

    Free delivery on orders over £100

    No hidden fees - price includes duty & taxes
    Rated 4.51 by 32,434 photographers

    Not happy? 14-day return period
The Wimberley AP-603 is a replacement foot for the Canon 200-400 IS, 300 2.8 IS II, 500 4.0 IS II and 400 4.0 DO IS II.

Wimberley AP-603 Replacement Foot - Canon 200-400 IS, 300 2.8 IS II, 500 4.0 IS II and 400 4.0 DO IS II

The Wimberley AP-603 Replacement Foot - Canon 200-400 IS, 300 2.8 IS II, 500 4.0 IS II and 400 4.0 DO IS II is an Arca-type compatible, black anodised 6061 aluminium foot with a dual dovetail mount for accessories that can be attached to both the top and bottom of the foot.

Compared to the foot originally supplied with the lens, the lower profile of this lightweight and durable replacement foot provides better balance when mounted on a tripod head. The lower profile also reduces flex and vibration during use.

Additionally, 1/4"-20 and 3/8"-16 connections are provided for tripod heads that do not have a compatible Arca-type clamp. Dual safety stops are included to prevent the lens from accidentally sliding if a clamp is partially open.

Information on the EU General Product Safety Regulation (GPSR)

Disnet B.V.

Bathoorn 4b, 9411 SE Beilen, The Netherlands

Features of the Wimberley AP-603 Replacement Foot - Canon 200-400 IS, 300 2.8 IS II, 500 4.0 IS II and 400 4.0 DO IS II

  • Arca-type compatible replacement lens foot
  • Low profile and low centre of gravity
  • Dual safety stops
  • Lightweight and durable
  • Reduces flexing and vibration
  • Black anodised 6061 aluminium
  • 1/4"-20 and 3/8"-16 connections
  • Dimensions: 12.2 x 4.3 x 3.6 cm
  • Weight: 147.4 grams
  • Compatible with Canon 300 f/2.8 IS II, Canon 200-400 f/4.0 IS, Canon 500 f/4.0 IS II and Canon 400 f/4.0 DO IS II

In the Box

  • Wimberley AP-603 Replacement Foot
  • 1/4"-20 mounting screw
  • 3/8"-16 mounting screw
  • 4 x M4 x 14mm hex bolts
  • 2 x M3 x 6mm hex bolts
  • 3 mm hex key with T-handle
  • 2.5 mm hex key
Dimensions & Weight
Length (mm) 122.0 mm
Weight (g) 147.0 g
Width (mm) 43.0 mm
Height (mm) 36.0 mm
General
Color Black
Accessory type Plate
Compatibility
Compatible with brand/series Arca-Swiss; Canon 200-400 IS
