SWIT Sony BP-U Series Battery Pack

Article number:

12546257

SWIT Sony BP-U Series Battery Pack
SWIT Sony BP-U Series Battery Pack
  • SWIT Sony BP-U Series Battery Pack
  • SWIT Sony BP-U Series Battery Pack
  • SWIT Sony BP-U Series Battery Pack
  • SWIT Sony BP-U Series Battery Pack
List price £325,-
£193,-

Delivered within 3 to 4 working days.

SWIT Sony BP-U Series Battery Pack
SWIT Sony BP-U Series Battery Pack
£193,-

Get notified

    Free delivery on orders over £100

    No hidden fees - price includes duty & taxes
    Rated 4.51 by 32,338 photographers

    Not happy? 14-day return period
The SWIT Sony BP-U Series Battery Pack is a new 90Wh BP-U DV battery with high capacity, D-tap output and 45W USB-C input/output, suitable for the Sony PXW FS5/FS7, PXW-FX6/FX9, PXW-Z200, HXR-NX800, PXW-Z280/X280, Blackmagic PYXIS 6K, etc.

SWIT Sony BP-U Series Battery Pack

The SWIT Sony BP-U Series Battery Pack is a new 90Wh BP-U DV battery with high capacity, D-tap output and 45W USB-C input/output, compatible with the Sony PXW FS5/FS7, PXW-FX6/FX9, PXW-Z200, HXR-NX800, PXW-Z280/X280, Blackmagic PYXIS 6K, and more.

The LB-SU90C consists of 8 battery cells, a nominal voltage of 14.4V and a high capacity of 90Wh/6200mAh to power cameras for extended periods. The continuous current load is 70W/6A. The LB-SU90C BP-U battery features a D-tap connector with a voltage of 11–16.8V and a high load of 70W/6A for various types of video equipment. You can also charge the battery via the D-tap connector of the SWIT PC-U130B2.

The LB-SU90C features a USB-C connector of 5V/9V/12V/15V/20V (max.) 2.25A, an output power of 45W for various types of laptops, tablets or smartphones, and supports BC1.2, PD2.0/3.0, QC2.0/3.0, FCP and SCP.

*(For the MacBook 13, MacBook Pro 13/15, ThinkPad New S2/T470/X270, Dell XPS 13/Latitude, HP Spectre x360-13/EliteBook Folio G1, Samsung Chromebook Plus, Google Pixelbook, Huawei Matebook, and more.)*

You can also charge the LB-SU90C via a USB-C charger. It supports 5V/9V/12V/15V/20V (max.) 2.25A, 45W input power, meaning you can fully charge the 90Wh battery within 3 hours.

4-level power indicator

Press the power indicator at the bottom; the 4-level LED lights indicate the remaining power.

The LB-SU90C can be charged using the separately available SWIT S-3602U 2-slot charger, SWIT PC-U130B2 D-tap charger or LC-D421 4-slot charger. With the LC-D421, you can charge 4 batteries simultaneously and fully charge them within 3.5 hours.

Information on the EU General Product Safety Regulation (GPSR)

SWIT Electronics Europe GmbH

Heerdterbuschstraße 10 / HALLE 9, 41460 Neuss NRW DE

info@swit-europe.com

+49 2131 6632331

Features of the SWIT Sony BP-U Series Battery Pack

  • Li-ion battery with nominal voltage of 14.4 V
  • Compatible with Sony BP-U batteries
  • Display of current information in the camera (some newer models)
  • Capacity: 90 Wh / 6.2 Ah
  • Built-in 14.4 V D-tap output / charging input
  • Built-in 45 W USB-C input and output
  • LED current indicator with 4 levels
  • Multiple circuit protections
  • Compatible with Blackmagic PYXIS 6K
  • Nominal voltage: 14.4 V
  • Maximum power: 70 W, 6 A / D-tap: 14.4 V, 70 W, 6 A / USB-C: 45 W input voltage: 5 V/9 V/12 V/15 V/20 V, 2.25 A / 45 W output voltage: 5 V/9 V/12 V/15 V/20 V, 2.25 A / BC1.2, QC2.0/3.0, PD2.0/3.0, FCP, SCP
  • Original batteries: Sony BP-U30, BP-U60, BP-U100
  • Compatible cameras: Sony PXW-FS5/FS7, PXW FX6/FX9, PXW-Z280/X280, PXW-Z200, HXR-NX800, Blackmagic PYXIS 6K etc.
  • Charging temperature: 0 - 40°C
  • Discharging temperature: -20°C - 50°C (capacity and maximum load may decrease when used below 0°C)
  • Dimensions: 70 x 42 x 96 mm
  • Weight: 462 grams

In the Box

  • 1x SWIT Sony BP-U Series Battery Pack
General
Compatible brand Sony
Power
Capacity (mAh) 6200.0 mAh
Chemistry Li‑ion
